Discover Pingcai’s FI Series outdoor LED billboard, available in P2.5– P10 pitches, with IP65 waterproof rating, high brightness, seamless splicing, and 24/7 stable operation.
The Pingcai™ FI Series is an all-weather, high-brightness outdoor fixed LED billboard display designed for large-scale advertising. Engineered for maximum durability, it features a waterproof iron cabinet with internal rubber sealing, built-in cooling fans, and IP65 protection, ensuring flawless 24/7 operation under all weather conditions.
Available in pixel pitches from P2.5 to P10, the FI Series offers up to 6500 nits of brightness, a ≥3840Hz refresh rate, and 140° wide viewing angles, delivering vibrant visuals in bright sunlight without color distortion. The system’s 960×960×200mm cabinet supports seamless splicing via CNC precision cuts and tool-efficient front or rear maintenance.
| Feature | Value |
|---|---|
| Pixel Pitches | P2.5 / P3.076 / P4 / P5 / P6.67 / P8 / P10 |
| Cabinet Size | 960×960×200mm |
| Module Size | 320×160×18mm |
| Cabinet Weight | 40 kg |
| Module Weight | 0.5 kg |
| LED Types | SMD1415 / SMD1921 / SMD2727 |
| Brightness | 5500–6500 nits |
| Refresh Rate | ≥3840Hz |
| Grey Scale | 14-bit |
| Contrast Ratio | ≥15,000:1 |
| Viewing Angle | 140° (H) / 140° (V) |
| IP Rating | IP65 (Front & Rear) |
| Cabinet Material | Waterproof Iron with anti-rust coating |
| Power Consumption | Max ≤800W/㎡ / Avg ≤330W/㎡ |
| Best Viewing Distance | ≥2.5m to ≥10m (varies by pitch) |
| Maintenance | Front or Rear Accessible |
| Operating Temp | –20°C to 50°C |
| Lifespan | ≥100,000 hours |
